Name: Az3 Welding Magnesium Alloy Pipe 0.5mm Az91 Tube
Brand: DOME
SKU: DM011
Price: 30 USD
Availability: InStock
Rating: 4.7 (138 reviews)

Home Products Magnesium Alloys

Az3 Welding Magnesium Alloy Pipe 0.5mm Az91 Tube

Product Details:

Place of Origin:	Zhengzhou,China
Brand Name:	DOME
Certification:	ISO9001,CE,SGS
Model Number:	DM011

Payment & Shipping Terms:

Minimum Order Quantity:	10KG
Price:	USD30~50/KGS
Packaging Details:	In carton, on pallet
Delivery Time:	7-15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

Detailed Product Description

Name:	Tubo De Magnesio Magnesium Alloy Pipe Az31 Magnesium Alloy Az91 Magnesium Tube	Delivery Time:	Within 15 Days
Diameter:	0.5-5.0 Mm	Color:	Silver Grey
Usage:	Welding	Chemical Composition:	Magnesium Alloy
High Light:	Welding Magnesium Alloy Pipe , 0.5mm Magnesium Alloy Pipe , Magnesium Alloy Az91 Tube

Tubo De Magnesio Magnesium Alloy Pipe Az31 Magnesium Alloy Az91 Magnesium Tube

Introduction:

Product Name	Tubo De Magnesio Magnesium Alloy Pipe Az31 Magnesium Alloy Az91 Magnesium Tube
Standard	AMS/ASTM/JIS/BS/ISO
Brand	AZ31B/ZK60A/AZ91D/AZ61A/AZ40M/AZ41M/AZ80A
Thickness	0.3mm-200mm
Width	customized Max.width 3000mm
Length	Customized
Application	transportation (automobiles, motorcycles, bicycles, rail transit, aviation); electronic products (computers, mobile phones, digital cameras, etc.); medical equipment (wheelchairs, crutches, rehabilitation fitness equipment, etc.) aerospace; textile High standards and diversified demands in the fields of printing machinery and automobiles.
Lead time	3 to 25 working days
Packing	Wooden pallet or according to customer's request

Application Area:Construction,Sports&Leisure,Transportation,Household Appliances and etc.

Parameter:

Model	Chemical Component(%):
Type	Mg	Al	Zn	Mn	Si	Fe	Cu
AZ31B	Bal.	2.50-3.50	0.60-1.40	0.20-1.0	≤0.08	≤0.003	≤0.001
AZ61A	Bal.	5.80-7.20	0.40-1.50	0.15-0.50	≤0.10	≤0.005	≤0.005
AZ80A	Bal.	7.80-9.20	0.20-0.80	0.12-0.50	≤0.10	≤0.005	≤0.005
AZ91D	Bal.	8.50-9.50	0.45-0.90	0.17-0.40	≤0.08	≤0.004	≤0.001

Resistance temperature factor (correction factor)
20℃	100℃	200℃	300℃	400℃	500℃	600℃	700℃	800℃	900℃ \| 1000℃ \|
1	1.005	1.014	1.028	1.044	1.064	1.090	1.120	1.142	1.142 \| 1.150

Alloy	Thickness(mm)	Tensile strength Rm (N/mm²)	Yield strength Rp0.2 (N/mm²)	Elongation (A%) 50mm
AZ31B	0.3-3.00	260	170	24.0
AZ31B	3.00-10.00	230	140	18.0
M2M	0.80-3.00	190	110	6.0
	3.00-5.00	180	100	5.0
	5.0-10.00	170	90	5.0
AZ40M	0.50-3.00	280	180	17.0
AZ40M	3.00-5.00	260	160	14.0
AZ41M	0.80-3.00	290	190	17.0
AZ41M	3.00-5.00	270	170	17.0
ME20M	0.80-3.00	250	170	21.0
ME20M	3.00-10.00	220	140	15.0

Az3 Welding Magnesium Alloy Pipe 0.5mm Az91 Tube 0

Applications:

The weldability of most magnesium alloys is good when proper filler metal in employed. A filler metal with a lower melting point and a wider freezing range than the base metal will provide good weldability and minimize weld cracking. AZ61A or AZ92A filler metals may be used to weld base metals of similar composition and also ZK21A base metal.

AZ61A filler metal is generally preferred for welding wrought base metals of those alloys because of lower cracking tendency. However, welds made in cast Mg-Al-Zn and AM100A base metals with AZ92A filler metal show less crack sensitivity. The weld metal will respond to the precipitation heat treatments normally applied to repaired castings. AZ101A filler metal may also be used to weld those cast base metals. EZ33A filler metal is used to weld wrought and cast base metals designed for elevated-temperature service; however, this filler metal should not be used for welding aluminum-bearing magnesium alloys because of severe weld cracking problems. When no other filler metal is available, most base metals may be welded with strips cut from the base metal.
