Name: AZ91D Customized Magnesium Alloy Plate 5mm With Good Rigidity
Brand: DOME
SKU: DM004
Price: 1 USD
Availability: InStock
Rating: 4.9 (170 reviews)

Home Products Magnesium Alloy Plate

AZ91D Customized Magnesium Alloy Plate 5mm With Good Rigidity

Product Details:

Place of Origin:	Zhengzhou,China
Brand Name:	DOME
Certification:	ISO9001,CE,SGS
Model Number:	DM004

Payment & Shipping Terms:

Minimum Order Quantity:	10Pcs
Packaging Details:	In carton, wooden case
Delivery Time:	3-25 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

Detailed Product Description

Product Name:	Easy To Use Customized Magnesium Alloy Plate With High Quality	Chemical Composition:	Magnesium
Alloy Or Not:	Yes	Shape:	Sheet Plate Bar Board
Extrusion Plate Thickness:	5mm-105 Mm	Extrusion Plate Width:	10 Mm-400 Mm
Rolled Plate Thickness:	0.3mm-5mm	Rolled Plate Width:	10mm-500mm
High Light:	Good Rigidity Magnesium Alloy Plate , AZ91D Magnesium Alloy Plate sheet , 5mm Magnesium Alloy Plate

AZ91D Easy To Use Customized Magnesium Alloy Plate With High Quality

Introduction of Magnesium Alloy Plate:

The AZ91D belongs to the cast magnesium alloy, mainly by the pressure mold casting into a manner, and can be changed by electrophoresis. It is characterized by a large strength, and corrosion resistance is greatly improved, which is mainly used for housing, small-size and shaped brackets of electrical products. A represents metal aluminum Al, Z represents metal zinc Zn, 9 represents aluminum content of 9%, 1 represents zinc content is 1%, and the last D is identifiable code. (National standard GB / T5153-2003)

Details of Magnesium Alloy Plate:

Type	Mg	Al	Zn	Mn	Si	Fe	Cu
AX31B	residual	2.5-3.5	0.60-1.4	0.20-1.0	≤0.08	≤0.003	≤0.001
AZ61A		5.8-7.2	0.40-1.5	0.15-0.50	≤0.10	≤0.005	≤0.005
AZ80A		7.8-9.2	0.20-0.80	0.12-0.50	≤0.10	≤0.005	≤0.005
AZ91D		8.5-9.5	0.45-0.90	0.17-0.40	≤0.08	≤0.004	≤0.001

Features of Magnesium Alloy Plate:

Magnesium alloy is the lightest metal, magnesium alloy strength, and stiffness of the magnesium alloy, and the impact resistance is better than aluminum alloy, which is widely used in automobiles, communication electronics, etc. The automotive industry is the most total amount of magnesium alloys, the best industries.

The magnesium alloy sheet is divided into sheets, medium plates, and thick plates. High thickboard strength, good rigidity, mostly used in aerospace military fields, while medium thin plates are used for civilian industries.

Due to the good thermal conductivity of magnesium, the cutting force is small, the heat dissipation speed during processing is very fast, and thus the tool life is long, the adhesive knife is small, so that the tool cost can be reduced, and the downtime required to replace the tool is shortened.

Because of magnesium is easy to cut, its chip performance is very good. Under normal circumstances, it can reach the desired final surface finish.
