Name: High Potential Mn Si Magnesium Alloy Welding Wire D300mm D270mm
Brand: DOME
SKU: DM011
Price: 30 USD
Availability: InStock
Rating: 4.5 (133 reviews)

Home Products Magnesium Alloy Welding Wire

High Potential Mn Si Magnesium Alloy Welding Wire D300mm D270mm

Product Details:

Place of Origin:	Zhengzhou,China
Brand Name:	DOME
Certification:	ISO9001,CE,SGS
Model Number:	DM011

Payment & Shipping Terms:

Minimum Order Quantity:	10KG
Price:	USD30~50/KGS
Packaging Details:	In carton, on pallet
Delivery Time:	7-15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

Detailed Product Description

Material:	Magnesium Alloy	Delivery Time:	7-15 Days
Diameter:	0.5-5.0 Mm	Color:	Silver Grey
Application:	Welding	Surface:	Smooth
High Light:	High Potential Magnesium Alloy Welding Wire , Mn Si Magnesium Alloy Welding Wire , 270mm Magnesium Alloy Wire

Magnesium Alloy Welding Wire For Electrical Wire Dimensionally Stable

some details of magnesium welding wire:

Item	magnesium welding wire
Material	magnesium alloy
Thickness	as customer's required
Width	as customer's required
length	as customer's required
size	customized
Features of Magnesium welding wire	1.fast heat dissipation,light,good rigidity
	2.Good corrosion resistance and dimensional stability
	3.Good impact resistance and wear resistance
	4.Good absorption of vibration energy performance
	5.high thermal and conductive properties
	6.non magnetic, good shielding and non-toxic characteristics.

Various Applications of magnesium welding wire:medical uses, car audio and 3C product and provides health and occupational safety.

Chemical compositions of cast magnesium anode (%)
Element	High potential	AZ63B	AZ63C	AZ63D
Al	<0.01	5.30-6.70	5.30-6.70	5.0-7.0
Zn	---	2.50-3.50	2.50-3.50	2.0-4.0
Mn	0.5-1.30	0.15-0.70	0.15-0.07	0.15-0.70
Si (max)	0.05	0.10	0.30	0.30
Cu (max)	0.02	0.02	0.05	0.10
Ni (max)	0.001	0.002	0.003	0.003
Fe (max)	0.03	0.005	0.005	0.005
Others each	0.05	---	--	---
Others total	0.30	0.30	0.30	0.30
Mg	Balance	Balance	Balance	Balance

Electrochemical Properties of cast magnesium anodes
Item	Open-circuit Voltage	Close-circuit Voltage	Actual capacitance	Current efficiency
	(-V)	(-V)	(A.h/g)	(%)
High Potential	1.70-1.75	1.57-1.62	≥ 1.100	≥ 50
Low Potential (AZ63)	1.50-1.55	1.45-1.50	≥ 1.105	≥ 50
Note: Open and Close-circuit voltage is relative to Saturated Calomel Electrode (SCE)
