0.3-10mm AZ31 AZ61 Magnesium Welding Wire High Thermal Conductivity

Product Details:

Place of Origin:	Zhengzhou,China
Brand Name:	DOME
Certification:	ISO9001,CE,SGS
Model Number:	DM011

Payment & Shipping Terms:

Minimum Order Quantity:	10KG
Price:	USD30~50/KGS
Packaging Details:	In carton, on pallet
Delivery Time:	7-15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Contact Now

Detailed Product Description

Material:	Magnesium Alloy	Delivery Time:	7-15 Days
Diameter:	0.5-5.0 Mm	Color:	Silver Grey
Application:	Welding	Surface:	Smooth
High Light:	AZ31 AZ61 Magnesium Welding Wire , 10mm Magnesium Welding Wire , High Thermal Conductivity Magnesium Wire

0.3~10mm Magnesium Welding Wire AZ31 AZ61 AZ91 Magnesium Alloy Wire Accept OEM

Advantage:

Pocessing, corrosion and mechanical properties have many characteristics: light weight, good rigidity, with a certain degree of corrosion resistance and dimensional stability, impact resistance, wear resistance, good attenuation and easy recovery; in addition to high thermal conductivity and conductivity Performance, non-magnetic barrier and non-toxic characteristics.

Type: magnesium alloy welding wire AZ31 AZ61 etc.

Specification: 0.3mm,1.2 mm, 1.5 mm, 2 mm, 2.4 mm, 3 mm,5mm,7mm etc. various specifications can be customized

Chemical compositions of cast magnesium anode (%)
Element	High potential	AZ63B	AZ63C	AZ63D
Al	<0.01	5.30-6.70	5.30-6.70	5.0-7.0
Zn	---	2.50-3.50	2.50-3.50	2.0-4.0
Mn	0.5-1.30	0.15-0.70	0.15-0.07	0.15-0.70
Si (max)	0.05	0.10	0.30	0.30
Cu (max)	0.02	0.02	0.05	0.10
Ni (max)	0.001	0.002	0.003	0.003
Fe (max)	0.03	0.005	0.005	0.005
Others each	0.05	---	--	---
Others total	0.30	0.30	0.30	0.30
Mg	Balance	Balance	Balance	Balance

Electrochemical Properties of cast magnesium anodes
Item	Open-circuit Voltage	Close-circuit Voltage	Actual capacitance	Current efficiency
	(-V)	(-V)	(A.h/g)	(%)
High Potential	1.70-1.75	1.57-1.62	≥ 1.100	≥ 50
Low Potential (AZ63)	1.50-1.55	1.45-1.50	≥ 1.105	≥ 50
Note: Open and Close-circuit voltage is relative to Saturated Calomel Electrode (SCE)
